DJI Dock 4
Rapid turnaround for remote operations
DJI Dock 4 is an automated docking and battery-swapping platform for DJI Matrice 5TD operations. It combines rapid turnaround with remote operation through DJI FlightHub 2 for response, site security, infrastructure inspection, agriculture, and mining workflows.
- Battery swap in controlled testing
- 25 seconds
- Dock protection rating
- IP56
- Specified operating temperature
- -40°C to 50°C
Automatic battery swapping for repeated missions
DJI specifies a 25-second battery swap, measured from full cover closure to completion of the swap in controlled conditions. Battery swapping and wireless charging help prepare the aircraft for its next task. The dock has four battery compartments, with a maximum of three occupied at once so the swapping mechanism can operate correctly.
Designed for fixed outdoor deployment
The dock is rated IP56 and has a specified operating temperature range of -40°C to 50°C. Compressor-based air conditioning and battery preheating support operation across changing conditions. It accommodates one aircraft and has a maximum allowable landing wind speed of 12 m/s.
Plan the complete system
DJI Dock 4 must be used with the DJI O4 Ground Station. The ground station is included with the Matrice 5TD combos listed separately; it is not listed in this Dock 4 package. The aircraft, required flight batteries, site preparation, connectivity, and software configuration should be confirmed when planning a deployment. A handheld remote controller is not included.
Remote workflows
DJI FlightHub 2 supports remote cockpit operation, route tasks, live streams, and workflow integration. Cloud and on-premises options have different capabilities and licensing requirements. Vehicle-mounted deployment is described by DJI as a future feature expected in the first half of 2027, subject to firmware updates; takeoff and landing while a vehicle is moving are not supported.
SpeedyDrone configuration guidance
Is DJI Dock 4 right for your site?
For Canadian buyers, this North American DOCK4-CB listing is the dock package. The aircraft and O4 Ground Station are supplied separately. Our guidance below applies DJI's published requirements to the purchasing decisions involved in a complete fixed-site deployment.
Match the aircraft first
Dock 4 operates with Matrice 5TD only. DJI's support for Matrice 4 Series and Matrice 4D Series during site surveys does not make those aircraft compatible with Dock 4 operations. Check the Matrice 5TD aircraft configurations before planning an upgrade.
Budget the complete system
Compare the dock, aircraft combo, flight batteries, installation work, connectivity and software scope together. Both listed Matrice 5TD combos include the O4 Ground Station; avoid budgeting for a second station unless the deployment design calls for it.
Define the mission before ordering
A recurring inspection route and an occasional response mission can require different battery rotation, network and software arrangements. Include your site location, operating hours, expected mission cadence and IT requirements in the configuration request so the equipment list can be checked against the intended work.
Compatibility basis: DJI Dock 4 FAQ. System roles: DJI installation manual, device topology. The configuration recommendations above are SpeedyDrone's planning guidance, not a completed site assessment.
Fixed-site deployment: what to confirm first
Use these checks to prepare a project brief before selecting installation materials or promising a mission schedule. DJI requires authorized technicians for installation and configuration; the current installation manual remains the detailed reference.
| Site and landing area | Survey both device locations and an alternate landing area. Start with an open, unobstructed layout and assess reflective surfaces, interference and future changes around the site. |
|---|---|
| Power and protection | Have the installer confirm stable AC supply, circuit capacity, earthing and lightning protection against the manual. The dock's input-power figure alone is not an installation design. |
| Network capacity | For a wired connection, DJI specifies more than 20 Mbps in each direction and recommends more than 40 Mbps. Test the actual connection at the planned ground-station location. |
| Ground-station placement | Use an elevated, unobstructed position. Maintain dock-to-station line of sight; the installation manual specifies cabling below 80 m and straight-line separation below 40 m. |
| Cold-site operation | Check seasonal conditions against the -40°C to 50°C range. DJI notes reduced aircraft performance below -20°C; temperature capability does not guarantee unchanged mission endurance. |
| Software and connectivity | Confirm the required FlightHub 2 deployment and features. For cellular access, verify compatible dongle, carrier coverage and data plan at the site rather than assuming Ethernet and cellular are interchangeable. |
Planning basis: DJI Dock 4 Installation and Setup Manual v1.0, construction safety and preparation, especially pages 20, 23–33 and 46–50.
For Canadian projects: use the site evaluation result and DJI's regional coverage rules to determine the supported deployment method. Do not assume that a demonstration beside a high-rise applies to every Canadian site. See the deployment-method eligibility guidance before committing to an obstructed location.
In the box
- DJI Dock 4
- Wind Speed Gauge Module, with mounting screws stored inside the dock
- Ethernet Cable Connector
- Power Cable Connector
- Expansion Bolts ×4
- Power Cable Wire Ferrules ×6
- 5 m Ethernet Cable
- USB-C to USB-C Cable
- Tool Kit
DJI Care Enterprise Plus
Eligible new DJI Dock 4 and Matrice 5TD devices receive one year of DJI Care Enterprise Plus with first activation and binding. Service starts at activation. Demonstration devices are excluded from the complimentary plan. Benefits, coverage limits, and renewal eligibility depend on the device and region.
Technical specifications
Dock - General
| Product Name | DJI Dock 4 |
|---|---|
| Total Weight | 66 kg (without batteries in the battery compartment, aircraft not included) The actual product weight may vary due to differences in batch materials and external factors. |
| Dimensions | Dock Cover Opened: 1750×640×550 mm (L×W×H) Dock Cover Closed: 639×640×836 mm (L×W×H) All data includes the wind speed gauge height (145 mm) and mounting base brackets (69 mm). |
| Input Voltage | 100-240 V (AC), 50/60 Hz |
| Input Power | Max 2000 W |
| Operating Temperature | -40° to 50° C (-40° to 122° F) |
| Ingress Protection Rating | IP56 |
| Max Operating Altitude | 5000 m |
| Number of Drones Accommodated | 1 |
| Max Allowable Landing Wind Speed | 12 m/s |
| RTK Base Station | Supported via DJI O4 Ground Station |
| Receiving Frequency of RTK Base Station Satellite | Supported via DJI O4 Ground Station |
Dock - Charging Performance
| Charging Method | Battery Swapping + Wireless Charging |
|---|---|
| Battery Swap Time | < 25 s Time elapsed from when the Dock Cover is fully closed to the completion of the battery swap. Measured in a controlled test environment and is for reference only. |
| Operational Turnaround Time | < 45 s Time elapsed from when the aircraft lands from the previous flight to when it completes the battery swap and takes off again. Measured in a controlled test environment and is for reference only. |
| Max Number of Batteries Stored Across All Battery Compartments | 3 The dock has four battery compartments, each designed to hold one battery. To ensure proper operation of the battery-swapping mechanism, no more than three of the four compartments may contain a battery at any given time. |
| Max Number of Parallel Charging Channels | 2 |
| Output Voltage | Per-channel output voltage: 15-25.8 V DC |
| Charging Time | Per-battery charging time: 27 minutes Time required to charge the battery in the battery compartment from 15% to 95% level in a 25° C (77° F) environment. |
Dock - Video Transmission
| Operating Frequency | High-speed Wi-Fi connection: 2.4000-2.4835 GHz: < 23 dBm (IC), < 20 dBm (CE/SRRC/MIC) 5.7250-5.8500 GHz: < 23 dBm (IC/SRRC), < 14 dBm (CE) DJI O4 Enterprise Enhanced Video Transmission System: Supported via DJI O4 Ground Station The supported operating frequency bands and their corresponding availability vary by country/region. For details, please refer to local laws and regulations. |
|---|---|
| Antenna | High-speed Wi-Fi connection: Single antenna DJI O4 Enterprise Enhanced Video Transmission System: Integrated into the O4 Ground Station |
Dock - Air Conditioning System
| Air Conditioning Type | Compressor-based air conditioning |
|---|---|
| Operating Voltage | 48 V DC |
Dock - Backup Battery
| Backup Power Supply Method | Backup power is supplied by the aircraft battery housed in the dock battery compartment. |
|---|---|
| Battery Capacity | 12138 mAh |
| Output Voltage | 21.42 V |
| Battery Type | LiNiMnCoO2 |
| Battery Life | Operating time per battery: approx. 4.5 hours Supports sequential power supply across three batteries Measured in a 25° C (77° F) environment with the backup battery discharged from 90% to 10%. After a power outage, the dock does not support functions like aircraft charging, air conditioning operation, and wind speed gauge heating. Please restore power promptly. |
Dock - Network Access
| Ethernet Access | Supported (requires connection to DJI O4 Ground Station) |
|---|---|
| 4G Access | Requires use with DJI Cellular Dongle 2 (installed on DJI O4 Ground Station). |
Dock - Sensor
| Wind Speed Sensor | Supported |
|---|---|
| Rainfall Sensor | Supported |
| Ambient Temperature Sensor | Supported |
| In-Cabin Temperature Sensor | Supported |
| In-Cabin Humidity Sensor | Supported |
Dock - Security Camera (External)
| Resolution | 1920×1080 |
|---|---|
| Field of View (FOV) | 151° |
| Auxiliary Light | Auxiliary White Light |
Dock - Security Camera (Internal)
| Resolution | 1920×1080 |
|---|---|
| FOV | 151° |
| Auxiliary Light | Auxiliary White Light |
Dock - Lightning Protection
| AC Power Port | 20 kA (rated value), meets EN 61643-11 Type 2 and IEC 61643-1 Class Ⅱ protection level requirements |
|---|---|
| Ethernet Port | 10 kA (Itotal), meets EN/IEC 61643-21 Category C protection level requirements |
Dock - Supported Software
| Applications | DJI Enterprise App (for on-site setup, testing, remote operations, live viewing, and one-tap drone dispatch) |
|---|---|
| Cloud Platform | FlightHub 2 FlightHub 2 On-Premises Version FlightHub 2 FlightHub Sync DJI Cloud API |
Performance figures are DJI laboratory measurements. Actual results depend on the environment, payload, configuration, software, and firmware. Follow the product manual and accessory instructions.
Explore DJI Enterprise accessories for supporting equipment.
Product identification
DOCK4-CB
| DJI part number | CB.202608035122 |
|---|---|
| Configuration | DJI Dock 4 (NA) SP Plus |
Contact SpeedyDrone Canada for pricing, availability, and help selecting a complete configuration.
SpeedyDrone Canada · Toronto
Plan your Dock 4 purchase with our Toronto team
SpeedyDrone Canada is a DJI and technology retailer based in Toronto, Ontario. Our team helps Canadian customers compare products, discuss purchase requirements and arrange eligible showroom pickup.
Toronto, ON M5S 3C4647-629-8799 ·
sales@speedydrone.ca
Configuration and purchasing guidance
Ask our sales team to review the dock alongside the separate Matrice 5TD combo, its included O4 Ground Station, battery quantities and software requirements. Share the site postal code, intended work, operating schedule and existing equipment so the purchasing scope can be discussed together.
Toronto pickup and Canadian delivery
Discuss your Dock 4 pickup or delivery requirements before ordering. Toronto pickup is available for eligible in-stock orders; this listing does not establish current showroom stock or a demonstration unit. For delivery elsewhere in Canada, request the shipping method, charges and timing for your destination. Check our Toronto showroom details and shipping information.
Order follow-up and service enquiries
SpeedyDrone can coordinate repair intake and forwarding to a repair partner. Repair work is performed by the partner; the specific equipment, acceptance, quotation and timing must be confirmed in writing before delivery to the store. See the repair-intake policy. Include any site installation, commissioning or training needs in your enquiry and request a confirmed service scope.
Frequently asked questions
Is the O4 Ground Station included with Dock 4?
The O4 Ground Station is required for Dock 4 operation but is not listed in this dock package. It is included with the separately listed Matrice 5TD combos.
Does this package include an aircraft or handheld controller?
The listed Dock 4 package does not include an aircraft or handheld remote controller. Confirm the complete deployment configuration and flight-battery quantity when ordering.
Which aircraft can operate from DJI Dock 4?
Only DJI Matrice 5TD. Matrice 4 Series and Matrice 4D Series are listed for site surveying, which is a separate role. See the official compatibility FAQ.
Does a 25-second swap mean the next flight starts 25 seconds after landing?
No. The swap figure starts after full cover closure. DJI separately lists operational turnaround below 45 seconds in controlled testing. Confirm real mission intervals during commissioning. See the charging-performance specifications.
How many flight batteries should I order?
The dock has four compartments but allows no more than three occupied at once. Order quantities should follow the aircraft, planned mission cadence and reserve strategy; ask SpeedyDrone to confirm the complete battery list. See DJI battery-compartment specifications.
Can backup power charge the aircraft?
No. DJI states that backup operation does not support aircraft charging, air conditioning or wind-speed-gauge heating. Include power continuity in the deployment plan. See the backup-battery limitations.
Where can I discuss a Dock 4 purchase in Toronto?
Contact SpeedyDrone Canada at 991B Bay Street, Toronto, ON M5S 3C4. The team can discuss products and purchasing requirements. Confirm Dock 4 stock, demonstration availability and pickup arrangements before visiting. See our Toronto showroom information.
Can SpeedyDrone assist with a Dock 4 purchase outside Toronto?
Yes. SpeedyDrone serves Canadian customers with sales enquiries and shipping. Include the project location and postal code in your Dock 4 quotation request; product availability, delivery method, charges and timing require confirmation. See our shipping policy.
What Dock 4 services should I confirm with SpeedyDrone?
Ask for confirmation of any site survey, installation, commissioning, training or ongoing support you require. For repair intake, SpeedyDrone requires a written arrangement before receiving equipment; repair work is performed by a partner. Review the repair-intake policy and contact the team about your specific Dock 4 case.
Official DJI documentation
- Dock 4 FAQ — aircraft compatibility, system requirements and operating questions.
- Dock 4 technical specifications — ratings, charging, turnaround and backup-power conditions.
- Installation and Setup Manual v1.0 (PDF) — site evaluation, mounting, electrical and network preparation.
- FlightHub 2 user guide — platform configuration and operating workflows.
- Dock 4 product overview and feature footnotes — regional availability and features requiring later updates.
Documentation reviewed October 14, 2026. Check DJI's current documentation and firmware notices when finalizing a deployment. Package contents for this listing follow the North American DOCK4-CB configuration; system illustrations do not add items to the package.
